| Type |
4 |
| Power Unit |
EE 16CSVT |
| Horse Power |
2,700 hp |
| Wheel Arrangement |
Co-Co |
| Weight In Running Order |
117 tons |
| Tractive Effort |
| Maximum |
48,500 lb |
| Continuous |
33,000 lb |
| Dimensions |
| Wheelbase |
56 ft 2 in |
| Bogie Wheelbase |
13 ft 6 in |
| Driving Wheel Diameter (new) |
3 ft 7 in |
| Bogie Centres |
42 ft 8 in |
| Width Overall |
8 ft 10⅜ in |
| Length Overall |
68 ft 6 in |
| Height Overall |
12 ft 9 1/16 in |
| Performance |
| Minimum Curve Negotiable |
4 chains |
| Maximum Service Speed |
100 mph |
| Capacities |
| Fuel Tank Capacity |
1,100 gallons |
Lubricating Oil Capacity
Engine sump, cooler, piping etc. |
130 gallons |
| Cooling Water Capacity |
| Including charge coolers etc. |
305 gallons |
| Jacket and Radiator |
200 gallons |
| Charge Cooler and Radiator |
80 gallons |
| Header Tank |
25 gallons |
| Brakes |
|
Compressed Air Rheostatic |
|
Locomotive Handbrakes |
|
Vacuum and Air Brakes |
